Introduction

In the oil & gas industries, ensuring the safety and efficiency of oil extraction requires real-time monitoring of oil pipelines and environmental safety parameters.

The EMQX MQTT platform can gather data from diverse IoT sensors, enabling the monitoring of pipeline parameters such as pressure, flow rate, and temperature, with abnormalities being promptly reported. Simultaneously, the MySQL database provides data storage and analysis capabilities, catering to both real-time monitoring and historical data analysis needs.

EMQX and MySQL together enable real-time monitoring of oil pipeline status and environmental conditions, improving safety and efficiency, and driving digital transformation in the oil & gas industries.

This blog will guide you through the process of using EMQX to collect sensor data from oil pipelines and integrating it with MySQL for real-time data storage and analysis.

The Role of MySQL in IoT

MySQL boasts distinctive advantages in the realm of IoT:

Structured Data Storage: MySQL stores data in the table, necessitating a predefined table structure and field data types. This structured approach ensures data consistency and integrity.
Powerful Query Language: With support for standard SQL queries, MySQL provides robust operations such as filtering, sorting, joining, and aggregating.
Scalability and Availability: Leveraging features like master-slave replication and sharding, MySQL enables high availability and horizontal scaling of data.
Transaction Processing: Supporting ACID transactions, MySQL ensures data consistency and reliability amid concurrent operations and system failures.

While MySQL excels in handling large-scale structured data and intricate queries, its structured data storage and powerful query language may not be optimal for telemetry data. Telemetry data, often classified as unstructured, demands high-speed write throughput and long-term storage capabilities.

In IoT applications, MySQL finds its niche in storing device metadata, event data, and a limited amount of telemetry data, such as device configuration, online/offline status, and current sensor readings. Managing these data is crucial for operational administration across the entire application, supporting both overall functionality and specific application scenarios.

Prerequisites

Git
Docker Engine: v20.10+
Docker Compose: v2.20+

How it Works

This is a simple and effective architecture that utilizes the following key components:

Component NameVersionDescriptionMQTTX CLI1.9.3+A command line tool for testing data generation.EMQX Enterprise5.0.4+An MQTT broker used for message exchange between pipelines and MySQL.MySQL4.4.6+A database for storing and managing oil production data, as well as providing time aggregation and analysis capabilities for Grafana.Grafana9.5.1+A visualization platform for displaying and analyzing collected data.

Clone the Project Locally

Clone the emqx/mqtt-to-mysql repository locally using Git:

git clone https://github.com/emqx/mqtt-to-mysql
cd mqtt-to-mysql

The codebase consists of four parts:

The emqx folder contains EMQX-MySQL integration configurations to automatically create rules and data bridges when launching EMQX.
The mqttx folder offers a script to simulate oil pipeline sensors connected to the EMQX and generating data.
The prometheus and grafana-provisioning folders contain configurations for visualizing energy consumption data.
The docker-compose.yml orchestrates all components to launch the project with one click.

Start MQTTX CLI, EMQX, and MySQL

Please make sure you have installed the Docker, and then run Docker Compose in the background to start the demo:

docker-compose up -d

The MQTTX CLI will simulate ten groups of sensor devices within EMQX. These devices will periodically publish real-time data, including oil pressure, casing pressure, back pressure, wellhead temperature, production, etc., from the pipeline to a designated topic. The transmitted data is formatted in JSON and sent to the topic mqttx/simulate/oil-extraction/{clientid}.

This is an example of data published to EMQX:

{
    "oilPressure": 1375829.01,
    "casingPressure": 429647.68,
    "backPressure": 142174.65,
    "wellheadTemperature": 75.03,
    "voltage": 360.84,
    "current": 29.4,
    "flowRate": 127.8,
    "id": "2eb9b000-c6a1-4af1-92c0-6e3026e2db92",
    "name": "oil_well_0"
}

Store Oil Pipeline Data

EMQX will create a rule to receive messages from each sensor. You can also modify this rule later to add custom processing using EMQX's built-in SQL functions:

SELECT
  payload
FROM
  "mqttx/simulate/#"

Once the rules have processed the data, EMQX will utilize rule actions to write the sensor data from the oil pipeline, present in the message payload, to the oil_well_data table within MySQL's iot_data database.

The EMQX MySQL data integration allows the insertion of data through SQL templates. This facilitates the effortless writing or updating of specific field data into corresponding tables and columns within the MySQL database. Such integration ensures flexible storage and management of data:

INSERT INTO oil_well_data
  (
    oil_well_id,
    NAME,
    oilpressure,
    casingpressure,
    backpressure,
    wellheadtemperature,
    voltage,
    CURRENT,
    flowrate
  )
  VALUES
  (
    ${payload.id},
    ${payload.name},
    ${payload.oilPressure},
    ${payload.casingPressure},
    ${payload.backPressure},
    ${payload.wellheadTemperature},
    ${payload.voltage},
    ${payload.current},
    ${payload.flowRate}
  )

Log Events from Acquisition Devices

Additionally, EMQX will create a rule to log the online and offline statuses of the acquisition devices connected to EMQX. This logging serves the purposes of device management and fault warning. If a device unexpectedly goes offline, immediate notification allows for prompt issue identification and resolution.

EMQX's rule engine extends support to the full MQTT device lifecycle event handling. For a comprehensive understanding and monitoring of various events through the rule engine, you can also refer here.

SELECT
  *
FROM
  "$events/client_connected",  "$events/client_disconnected"

Upon successful connection or disconnection of a device, EMQX activates the rule and records the event in the oil_well_events table within MySQL's iot_data database.

The recorded information encompasses the event name and client ID, with the event time being automatically generated by MySQL:

INSERT INTO oil_well_events(event, clientid) VALUES(${event}, ${clientid})

Subscribe to Data from EMQX

Docker Compose has included a subscriber to print all vehicle data. You can view the data with this command:

$ docker logs -f mqttx
[1/12/2024] [10:15:57 AM] › topic: mqttx/simulate/oil-extraction/mqttx_4f113a38
payload: "oilPressure":1375829.01,"casingPressure":429647.68,"backPressure":142174.65,"wellheadTemperature":75.03,"voltage":360.84,"current":29.4,"flowRate":127.8,"id":"2eb9b000-c6a1-4af1-92c0-6e3026e2db92","name":"oil_well_0"}

To subscribe and receive the data with any MQTT client:

mqttx sub -t mqttx/simulate/oil-extraction/+

View Pipeline Data through Grafana

To access pipeline data on the Grafana dashboard, navigate to

http://localhost:3000

in your browser and log in using the credentials admin (username) and public (password).

After logging in, visit the Home → Dashboards page and choose the Oil Extraction dashboard. This dashboard provides a comprehensive overview of your oil pipeline, featuring real-time metrics such as current oil pressure, casing pressure, back pressure, wellhead temperature, and more. Additionally, it displays trends in these metrics over time. The visualization of these key metrics facilitates visual monitoring of the production status, enabling the prompt identification of any potential anomalies or issues.

Conclusion

In this blog, we delve into the integration of EMQX and MySQL to construct a comprehensive oil extraction monitoring application. By utilizing EMQX as a real-time MQTT Broker and seamlessly importing data into MySQL, we have successfully implemented an end-to-end solution for the acquisition and analysis of oil extraction data.

This demo serves as a blueprint for building a scalable platform dedicated to monitoring petroleum and petrochemical data. It empowers real-time surveillance of production data and equipment status. Leveraging the reliability of EMQX and the robust storage and analytics capabilities of MySQL, we can enhance operational efficiency, minimize downtime, and bolster safety through data-driven analytics and proactive maintenance of production lines.

EMQ offers a complete solution that includes data acquisition, edge computing, cloud access, and AI technology for the oil and gas industry. It integrates data from wells, edge gateways, and cloud applications into a unified platform. This enables various scenarios such as production monitoring, maintenance, safety and environmental oversight, and asset tracking, further accelerating the digital transformation and advancement of the industry.

For detailed information, please refer to MQTT Platform for Oil & Gas Industry.
